AF1 Auger Filler — Specification Sheet

Features:

Touchscreen control package
Job/recipe memory
Stainless steel construction

Options:

Additional fill heads
Sanitary conveyor system
Dust collector
Product vibration to tamp product in the container during the fill cycle

AF1 fillers are well-suited for filling dry products, powders, granules, or seeds. The simple filler design allows for easy cleanup, maintenance, and rapid changeover. Each machine is based on a heavy-duty stainless steel frame with all contact parts made of food-grade materials.

This machine has an optional vacuum hood that collects dust generated by the filling process. The vacuum hood connects to a dust collector that sucks the dust out of the filling area and recoups the product for reuse.

The AF1 machines use high-tech brushless, direct-drive servomotors, and state-of-the-art motion control electronics for the auger control. A PLC-based touchscreen control system ensures the filler’s accuracy.

The AF1 Automatic Auger Fillers, available in semi-automatic and fully automatic configurations, are the best choice for accurate, repeatable filling.

Contact Accutek Packaging Equipment Company, Inc. today to learn more about this filling machine.

Standard Specification:

Dose Size	.006 – 50 lbs (3 g– 22.68 kg)
Fill Size	.001 – 4.4 lbs (0.5 g – 2 kg)
Product Speed	Up to 20 CPM
Electrical	220 Single-phase
Height	~79.5” (201.93 cm)
Length	~33” (83.82 cm)
Width	~31.75” (80.65 cm)
Weight	Apx. 430 lbs. (195 kg)

Machine specifications are based on the machine configuration. Any options or modifications may affect these specifications.
