APS 106

The APS-106 is economical, self-contained and easy to operate. This automatic labeling system comes equipped with a 6 ft. variable speed conveyor.

The APS-106 is economical, self-contained and easy to operate. This automatic labeling system comes equipped with a 6 ft. variable speed conveyor. Additional features include a stepper motor drive for label, power assisted web take up, full wrap around or tamp station, auto speed adjust (all motors synchronized), and Photo Eye (non contact) sensors for label gaps and containers.

The easy-to-use design makes it simple to change bottle and label sizes. The APS-106 can dispense up to a 5.75” tall labels. It is available with one or two labeling heads for single or front and back containers. The speed, versatility, and reliability of the APS-106 is comparable to and in many cases exceed the other industry lead­ers in labeling equipment technology-usually at a fraction of the price. Our Labelers are ideal for all plastic, metal, fiber, and glass containers. The APS-106 handles cylindrical containers.



Features:
    • Auto Label Learn™ (Automatic label setup)
    • Label head dispenses up to 5.75″ tall labels
    • Touch screen control system with job memory
    • Heavy duty construction for 3 shift operations
    • Sanitary stainless-steel frame
    • Easy adjusting hand wheels for quick setup
    • Fully synchronized conveyor / label head, with 8 different speed selections
    • Height adjustable conveyor
    • Maximum roll diameter of 13.5″
Options:
    • Hot Stamp Coder
    • Pneumatic Separator
    • 3 Roller System (Registration & Long Labels)
    • Clear Label Sensor



Standard Specifications:

  • Dimensions: Length: 80”, Width: 28”, H:42” (203.2 cm”),(W: 71.12cm)(H: 106.68cm)
  • Weight: ~347 lbs
  • Electrical Requirements: 110 VAC, 10AMPS (220 VAC Optional)
  • Air Requirements: None
  • Labeling Speed: Up to 165 CPM
  • Label Size: Label Length: 0.5” – 15” – Label Height: 0.5” – 5.75”
  • Labeling Direction: Left side off – Outside peel
