CO2 Laser marking Machine
A carbon dioxide (CO2) laser marking machine is a sophisticated tool for precise and efficient marking, engraving, or etching various materials. It uses a CO2 laser beam to create highly detailed and permanent markings with fine details and sharp edges.
It can mark a wide range of materials, making it suitable for manufacturing, electronics, automotive, medical devices, and packaging.
The marking process is non-contact, minimizing the risk of damage to delicate materials and eliminating the need for consumables like ink or dyes. CO2 laser marking machines can achieve high marking speeds, allowing for efficient production throughput.
The CO2 laser source is the system’s core, emitting a concentrated infrared beam at approximately 10.6 micrometers that is absorbed by wood, paper, plastics, glass, leather, and some metals.
The marking head, which houses the focusing lens and mirrors, directs and focuses the laser beam onto the material surface. It integrates a galvanometer scanner system for rapid, controlled movement, ensuring fast and accurate marking.
Users can adjust parameters like power, speed, and design for various marking applications. The workstation provides a platform for the material, featuring a motorized Z-axis for adjusting focal distance, a rotary attachment for cylindrical objects, and a fume extraction system to clear debris.
Cooling systems, either water- or air-based, dissipate heat generated during laser operation, maintaining optimal performance and extending the laser source’s lifespan. These systems can integrate into production lines or machinery for inline marking and offer connectivity options like Ethernet or USB for data transfer and control.
This machine is excellent for products in the manufacturing, electronics, automotive, medical, and aerospace industries.
Contact Accutek today to learn more about this machine.
Recommended Products
Steel, aluminum, copper, brass, titanium, gold, silver, and various alloys, including ABS, acrylic, polycarbonate, polypropylene, PVC, porcelain, tiles (though this may require specialized laser settings to avoid cracking or shattering), anodized metals, painted surfaces, and certain types of coatings
What should I do if I have a problem with the printer?
The laser printer’s manual has a thorough diagnosis/troubleshooting section that will walk you through resolving various potential problems. If it doesn’t help or the issue you’re having is outside of the manual’s scope, give our service department a call.How do I best clean and maintain this machine?
We recommend performing maintenance whenever you use the printer for more than 12 hours per day. You should also perform maintenance if your work environment is highly polluted. At that point, you should perform preventative maintenance every month, every three months, and every six months.- Infrared beam positioning
- Infrared beam focusing
- Support components
- Smoke absorption purifier
- Laser Type: 10.6um/10.2um/9.3um CO2 laser
- Laser Power: 30 W/40 W/50 W/60 W
- Characters Per Second: 1200 – 1500 (According to different types of printers)
- Character Height: 0.8 mm – maximum printing range
- Font: 26 fonts; users can customise the font type
- Machine-readable Code: Barcode, QR code
- Mark/Symbol: BMP/DXF/HPGL/JPEG
- Communication Interface: USB, Ethernet, RS232
- Operating Environment Temperature: 41 – 113 °F (5 – 45 °C)
- Cooling System: Air cooling
- Relative Humidity: 10% – 90% (no condensation)
- Printing Speed: 200 m/min – 300 m/min
- Electrical Requirements: 100/240 V (auto-adaptation), 50/60 Hz, 750 W
- Laser Head Dimensions:
- Length: 27.76″ (705 mm)
- Width: 6.93″ (176 mm)
- Height: 6.14″ (156 mm)
- Weight: 33 lbs (15.0 kg)
- User Interface Dimensions:
- Length: 11.81″ (300 mm)
- Width: 7.87″ (200 mm)
- Height: 2.36″ (60 mm)
- Weight: 4.4 lbs. (2.0 kg)
