How exactly does this machine work?

The nozzle T has two check valves inside of it; product is pulled into the product cylinder from the hopper through the upper check valve by the position retracting inside the product cylinder. A servo driving a ball screw beneath the platform moves the piston. The fill volume is determined by the inside diameter of the product cylinder and the piston stroke length.

Does the touchscreen make this easier to operate than the other volumetric fillers?

The touchscreen gives you significantly more control and customization options for filling your containers with product.

What does the optional heat and mixer package do?

These are for when you have a product that needs to be at least above room temperature to flow. The heaters and mixer need a control box to handle the electronics. There’s a ball valve that directs product from the hopper to flow into the cylinder during the draw stroke. It directs product to the nozzle during the fill stroke.

How often does this machine need to be cleaned and maintained?

How frequently you need to clean your machine, and the type of cleaning solution you use, will be dependent on what exactly you’re using your machine for. But it’s best to consider your local and federal guidelines. We do recommend cleaning this machine with a mild soap solution, then rinsing it with water.

• Foamy Product: Yes
• Corrosive Product: Yes
• Heated Product: Yes
• Particulates: Yes
• Fill Quantity: 2– 128 oz (59.15 mL – 3.79 L)
• Air Requirements: 0 PSI
• Electrical Requirements: 110VAC VAC / Single Phase / 5 Amp
• Height: 62.75” (159.39 cm)
• Length: 43” (109.22 cm)
• Width: 28.5” (71.39 cm)

• Single-head filler configuration
• Multi-stroke operations (multiple doses per container)
• Direct from drum draw kit
• Sanitary contact parts and fluid path

• Thin nozzles (for products that string or drip)
• Long nozzles (for bottom-up filling to reduce foam)
• Chunky product butterfly valves for products with particulates
• Heat or corrosive product packages (contact parts and tubing)
• Positive off nozzles
• Product suck-back kits (prevents dripping)
• Sanitary stainless-steel hoppers
• Footswitch control
• Standalone frame with or without casters
