SAPD-2 Positive Displacement Filling Machine

Product Variants

SAPD-1

SAPD-1

The Semi-Automatic 2-Head Positive Displacement filling machines use a positive displacement pump head for each fill head, offering superior control and accuracy. Its advanced PLC control package lets operators precisely control each fill head using encoding technology for fractional control of the pump head.

Each fill head can be programmed to initiate the filling process gradually and increase to full speed before slowing down to complete the fill. Post-filling, the pump filler can reverse to prevent dripping as it withdraws excess product from the nozzle, readying it for the next fill. The pump heads are available in sanitary 4-GPM and 10-GPM options.

This filler is ideal for higher-viscosity products and applications requiring high accuracy. It boasts versatility to accommodate various container sizes, fill volumes, and product types, making it suitable for multiple applications.

The SAPD-2 is a perfect choice for both large production runs and start-ups. Contact Accutek today to learn more about this machine.

Is the SAPD-2’s touchscreen easy to use?

Yes, absolutely. While it may not be immediately obvious which button does what, our manual thoroughly goes over how to navigate the touchscreen. You’ll be able to carry out filling cycles with confidence and ease.

What should I do if I run into an issue with the machine?

The manual has a section on how to troubleshoot some basic problems you may come across. If you use any of the suggested solutions and they don’t work, or the issue in question is beyond the scope of the troubleshooting section, then you may need to call Accutek’s service department. We’ll be happy to help you navigate through the issue.

How often should I clean and maintain the machine?

How frequently you clean and maintain your machine is going to depend on how often you use it and what product you use it for. Generally, we recommend cleaning and maintaining the more you use it. We advise against using caustic, bleach, or acid solutions, since they can erode the machine’s stainless steel and aluminum components.

Foamy Product: Yes
Corrosive Product: Yes
Heated Product: Yes
Particulates: No
Product Filling Speed: Approx. 40 CPM
Fill Size: 0.5 oz – 5 gallons (14.79 mL – 18.93 L)
Viscosity Range: 0 – 18,000 cP
Electrical: 110/240 VAC / Single Phase / 40 AMP
Air Requirements: 80 PSI
Height: 64” (162.56 cm)
Length: 35“ (88.9 cm)
Depth: 48” (121.92 cm)
Weight: Approx. 300 lbs. (136.08 kg)

Sanitary stainless-steel base
Reinforced food-grade tubing
Stainless-steel gear pump with Ryton gears
Adjustable volumetric fill by pump revolutions
Independent fill heads
Manual fill head height adjustment
Easy to program
30-job memory
Sanitary stainless-steel control valve for tank
PLC control box
4-GPM (optional 10-GPM) positive displacement pumps
Stainless-steel hopper with liquid-level assembly

Automatic diving nozzles
Positive-off nozzles
Hazardous location electrical controls
Powered fill head height adjustment
Container neck orienter
Sanitary connections
Gear materials stainless steel/plastic
10-GPM pump
