APD Series
From water to thicker liquids, KISS Automatic Positive Displacement Fillers have been built to handle some of the most viscous liquid products on the market.
Advanced PLC controls allow operators to control product flow and speed to each filling head accurately. The fillers are programmed with an upsurge fill cycle, which reduces splashing and delivers precise fills for viscous products.
Automatic Positive Displacement fillers specialize in filling viscous liquids and can fill those products in larger volumes faster than other filler types.
These machines include 4-GPM pump heads (10-GPM optional) and can accommodate various container sizes, fill volumes, and product types.
Automatic models are manufactured with heavy-duty sanitary stainless steel and include height-adjustable frames, a 10-foot-long variable-speed conveyor, and touchscreen controls with an automatic bottle-indexing unit. Each machine has four height-adjustable articulating feet but can be upgraded with heavy-duty locking casters for easy movement.
APD Fillers are ideal for filling a wide range of viscosities and with various options can replace multiple machines because of their flexibility and speed.
Contact Accutek to learn more about these machines.
Recommended Products
- Juices
- Vitamin drinks
- Syrups
- Dressings
- Milk
- Honey
- Jellies
- Perfumes
- Hair conditioner
- Liquid soap
- Shampoo
- Creams and lotion
- Hand and body wash
- Hair styling gels
- Mascara
- Eyeliner
- Makeup remover
- Detergents
- Oils
- Liquid cleaners
- Paint
- Degreasers
- Engine coolant
- Varnish
- Candles
- Sealants
- Grease
- Glue
- Silicone
- Cough medicine
- Iodine
- Saline solutions
- Insect repellent
- And much more
What does the optional heater and mixer package do?
How often should I clean and maintain the machine?
- Foamy Product: Yes
- Corrosive Product: Yes
- Heated Product: Yes
- Particulates: Yes (with pump upgrade)
- Fill Size: 0.5 oz to 5+ gallons (147.87 mL to 18.93 L)
- Viscosity Range: 1-18000 cP
- Speed: Up to 100 CPM
- Electrical Requirements: 220/240 VAC / 3-phase / 40 AMP
- Air Requirements: 120 PSI @ 6-12 CFM
- Height: 96” (243.84 cm)
- Length: 128” (325.12 cm)
- Width: 48” (121.92 cm)
- Weight: ~1800 lbs. (816.47 kg)
- Complete sanitary stainless construction with leveling feet
- 4 to 12 fill nozzles
- Sanitary stainless steel manifold with quick clean connection
- Stainless-steel valve for product flow control to buffer tank
- Sanitary stainless steel buffer tank
- Reinforced food-grade tubing
- Sanitary stainless-steel gear pump with Ryton gears
- Star wheel indexing
- Filling station verification and counter
- Batch counter with lockout feature
- Save up to 30 different product setups
- Individual height adjustment of fill heads
- 10’ long 4.5” wide stainless-steel variable speed conveyor
- Drip tray
- Container neck locator
- Diving heads
- Positive off nozzles
- Star wheel bottle indexing
- Application-specific pump heads
- Sanitary conveyor system
- Safety or PAR frame for operator protection
