APS-236

The APS-236 is a specialized dual head labeler designed specifically for top and bottom label applications. Ideal for all plastic, metal, fiber, and glass containers, trays, and tubs its dual label heads can simultaneously dispense different size labels up to 6 inches (15.24cm) tall and 11 inches (28cm) long.

Compatiblity

Description

The APS-236 is a specialized dual head labeler designed specifically for top and bottom label applications. Ideal for all plastic, metal, fiber, and glass containers, trays, and tubs its dual label heads can simultaneously dispense different size labels up to 6 inches (15.24cm) tall and 11 inches (28cm) long. The APS-236 easily adjustable, electronically controlled placement sensor insures accurate and symmetric placement.
APS-236 labelers also include a stepper motor drive with synchronized auto speed adjust for continuous label placement while changing speeds. Power assisted web take up to manage label roll waste. A full tamp station to insure wrinkle free application. Like Labelette Automatic Labelers the APS-236 also include label learn and job save to make setup and changeovers a snap.



Features
    • Auto Label Learn™
    • Dual Label Heads for Top and Bottom Labeling
    • Label Head Can Dispense 6” (15 cm) Tall Labels
    • In Line Automatic Applications or Semi Automatic Use
    • Touch Screen Control System with Job Memory
    • Heavy Duty Construction for 3 Shift Operations
    • Sanitary Stainless Steel Frame
    • Easy Adjusting Hand Wheels for Quick Setup
    • Fully Synchronized Conveyor / Label Head,
    • with 8 Different Speed Selections



Options
    • Hot Stamp Date/Lot Coder
    • Alpha Numeric Starter Kit
    • Pneumatic Separator
    • Clear Label Sensor
    • Star Wheel Separator
    • Conical Label Heads for Curved Packages
    • Casters



Specs
Height: 60” (152.4 cm)
Length: 68” (172.7 cm)
Depth: 40” (101.6 cm)
Weight: Approx. ~425 lbs. (193 kg)
Electrical: 110 VAC, 60 Hz, Single Phase (220VAC Optional)
Label length: 0.5”-11” (1.25-28 cm)
Label Heigh: 0.5” – 6” (1.9-15.25 cm)
