Do I need any particular tools for the setup?

We recommend using four hex socket and three metric open-end wrenches, two screwdrivers, and one pair of circle-clip pliers for setup. The manual will otherwise discuss the steps for setup.

How can I best maintain the case taper?

We DO NOT recommend using compressed air to clean out the machine. Otherwise, components, such as the motor, could face unnecessary wear. Instead, use a designated shop vacuum. You do not need to lubricate the bearings, as they are permanently lubricated.

What do I do if the case taper has a problem?

If you experience any issues with your case taper, then we recommend that you consult the manual. It contains a troubleshooting section that describes possible faults, their causes, and how to fix them. If you’re still having problems, feel free to give Accutek a call so our service technicians can assist you.

• Left and right drive belts
• 2″ top and bottom tape applicators
• Tape overlap length can be adjusted from 5 mm to 50 mm
• Roller working table
• Blade guards
• Crank handle adjustments for carton width and height
• Leg height adjustment
• Roller infeed and exit conveyors
• Casters for portability

• Three-inch tape head

• Electric: 110 VAC – 15 Amp
• Length: 72″ (182.88 cm)
• Width: 33″ (83.82 cm)
• Height: 52″ (132.08 cm)
• Weight: 353 lbs. (160.12 kg)
• Minimum Case Height: 5.9″ (15 cm)
• Maximum Case Length: 23.62″ (60 cm)
• Maximum Case Width: 23.62″ (60 cm)
• Maximum Case Height: 23.62″ (60 cm)
